Full Description

The recommended design approach is described. The approach emphasizes the fundamental relationship between symbols, the information they encode, the context within which the symbols are displayed, and the tasks being supported. While this document is aimed at aircraft displays involving dynamic control or monitoring tasks, the methodology is applicable to a wide range of symbology development situations.

This document outlines a recommended approach for the design of integrated display symbology in support of flight tasks.

Product Details

Published: 02/16/2008 File Size: 1 file , 160 KB
