Full Description

This guide is intended to cover test procedures applicable to MAP transducers; it is also applicable to transducers such as Barometric (Ambient) Absolute Pressure transducers, Manifold Vacuum transducers, and similar pressure transducers used in automotive systems. Although oriented towards active devices (those using internal signal conditioning), it can be applied to passive devices with minor modifications.
