Full Description

This document describes the design and assembly force guidelines for conventional and mechanical assist (lever and slide-lock) electrical connectors and CPA's. All possible designs and applications cannot be anticipated in creating these guidelines. Where there are questions of adherence to this document, such as use of an "off-the-shelf" design, always consult the responsible Ergonomics department. Refer to SAE/USCAR-12 Wiring Component Design Guidelines for additional guidelines.

Product Details

Published: 05/03/2003 File Size: 1 file , 460 KB
