Full Description

The range of test conditions on the dynamometer shall be sufficient to determine the primary operating characteristics corresponding to the full range of vehicle operations.

The characteristics to be determined are:

Torque ratio versus speed ratio and output speed

Input speed versus speed ratio and output speed

Efficiency versus speed ratio and output speed

Capacity factor versus speed ratio and output speed

Input torque versus input speed

NOTE: For more information about these characteristics and the design of hydrodynamic drives, see “Design Practices—Passenger Car Automatic Transmissions,” SAE Advances in Engineering, AE18 or AE29
