Full Description

This recommended practice is intended to provide a framework for performance testing of fuel cell systems (FCS’s) designed for automotive applications with direct current (DC) output. The procedures described allow for measurement of performance relative to claims by manufacturers of such systems with regard to the following performance criteria.

Power

Efficiency

Transient Response

Start and Stop Performance

Physical Description

Environmental Limits

Operational Requirements

Integration

Since this recommended practice is based on the principal of performance measurement relative to a claim, the testing parties should take care to include any qualifying or unique circumstances leading to the test results reported in order to achieve full disclosure. For example, efficiency as defined in section 3.1.9 allows for the inclusion of thermal output benefit. If a test result is reported which takes advantage of this allowance this stipulation should be noted with the efficiency figure and the useful purpose of the thermal output (e.g. cabin heating) should be made clear.
