Full Description

This document defines a physical layer having a higher bandwidth capacity than other physical layers defined for SAE J1939. Newer transceiver technologies are utilized to minimize EMI.

This SAE Recommended Practice is intended for light- and heavy-duty vehicles on- or off-road as well as appropriate stationary applications which use vehicle derived components (e.g., generator sets). Vehicles of interest include but are not limited to: on- and off-highway trucks and their trailers; construction equipment; and agricultural equipment and implements.

Implementing a robust CAN network involves many tradeoffs affecting both the network layout and ECU design. This document presents a standard by which ECUs, tools, and vehicle networks from different sources may be compatible. The document is intended to stand alone, yet borrows from the many existing standards and papers for its methodology.

Product Details

Published: 10/05/2011 File Size: 1 file , 160 KB
