Full Description

This document supersedes SAE J1962 FEB1998, and is technically equivalent to ISO/DIS 15031-3:December 14, 2001.

The SAE J1962 diagnostic connector consists of two mating connectors, the vehicle connector and the test equipment connector. This document: a. Defines the functional requirements for the vehicle connector. These functional requirements are separated into three principal areas: connector location/access, connector design, and connector terminal assigments; b. Defines the functional requirements for the external test equipment connector. These functional requirementsare separated into two principal areas: connector design and connector terminal assignements.

The scope of this document does not include the needs of long-term retention, such as in-flight recorder type applications. To ensure long-term retention, additional steps outside of the scope of this document must be taken.
