Full Description

The purpose of SAE J 2337 specifies dimensions, design, and performance requirements for eight plugs using a conical seal to insure leak proof performance with a design factor of 4 to 1.

These connectors are intended for general and hydraulic systems on industrial equipment and commercial products, where elastomeric seals are acceptable to overcome leakage and variations in assembly procedures. These connectors are capable of providing leak proof full flow connections in hydraulic systems operating from 95 kPa vacuum to the working pressures shown in Table 1. Since many factors influence the pressure at which hydraulic systems will or will not perform satisfactorily, these values should not be construed as guaranteed minimums. For any application, it is recommended that sufficient testing be conducted and reviewed by both the user and manufacturer to ensure that the required performance levels are met.

Product Details

Published: 10/01/2002 File Size: 1 file , 100 KB
