Full Description

The three parts of SAE J1453 cover material, dimensional, and performance requirements of steel O-ring face seal (ORFS) connectors for tubing and the O-ring face seal interface and nut portion of hose stem assemblies for nominal tube diameters of 6 mm through 50 mm. SAE J1453-3 covers the requirements for O-ring face seal connectors to inch stud ends along with the associated adapters, bulkhead and union connectors. Inch hex dimensions of parts will be moved from the main document to an informative annex after 2013.
