Full Description

This SAE Recommended Practice describes two-dimensional, 95th percentile truck driver, side view, seated shin-knee contours for both the accelerator operating leg and the clutch operating leg for horizontally adjustable seats (see Figure 1). There is one contour for the clutch shin-knee and one contour for the accelerator shin-knee. There are three locating equations for each curve to accommodate male-to-female ratios of 50:50, 75:25, and 90:10 to 95:5.

Product Details

Published: 12/03/2014 File Size: 1 file , 550 KB Redline File Size: 2 files , 3.1 MB
