Full Description

Specifies the dimensional characteristics of the basic rack, having a constant bottom clearance. In these gear pairs the tip angle of one gear is equal to the difference between the designed shaft angle and the root angle of the mating gear. Gives profile and some notes and defines the terms basic rack and reference line.
