Full Description

This International Standard specifies the dimensions of parallel shank socket reamers and taper shank socket reamers manufactured to produce self-holding taper sockets for self-holding taper shanks of the following designations, and which are in accordance with ISO/R 296 :

metric Tapers No. 4 and No. 6;Morse Tapers No. 0 to 6 inclusive.

Values are given, in millimetres and inches, for the following dimensions of these tools:

gauge plane diameter d;overall length L;cutting edge length l;distance from gauge plane to tool end l₁;diameter of shank d₁, or Morse taper shank size.

The taper on diameter is also shown.

The shanks and driving squares of the tools are in accordance with ISO/R 237.

The Morse taper shanks are in accordance with ISO/R 296.

Unless otherwise stated these reamers will be right hand cutting.

Product Details

Published: 05/01/1972 Number of Pages: 3 File Size: 1 file , 190 KB
