ISO 2594:1972
M00001095
New product
ISO 2594:1972 Building drawings -- Projection methods
standard by International Organization for Standardization, 09/01/1972
In stock
More info
Full Description
Two methods are defined and the symbols specified as shown in the figures. The direct orthogonal projection is symbolized by two parallel arrows running vertically to a dash-and-dot line, and the mirror-inverted orthogonal projection by two parallel double arrows running vertically to a dash-and-dot line.
