Full Description

Gives the dimensions of 19 mm and 38 mm bore pressure connections. A space envolope is also specified for each size of connection. Dimensions and tolerances for connections are given in figures 1 and 3, and those for space envelopes in figures 2 and 4. The values are listed in tables.
