ISO 13715:2017
M00000298
New product
ISO 13715:2017 Technical product documentation - Edges of undefined shape - Indication and dimensioning
standard by International Organization for Standardization, 03/01/2017
In stock
More info
Full Description
ISO 13715:2017 specifies rules for the indication and dimensioning of undefined edges in technical product and dimensions. The proportions and dimensions of the graphical symbols to be used are also specified.
In cases where the geometrically defined shape of an edge (for example, 1 × 45°) is required, the general dimensioning principles given in ISO 129-1 apply.
