Full Description

Includes maximum and minimum dimensions for clamps installed by means of two bolts with nominal diameters of 5 mm. The specified dimensions define a dimensional envelope. Shall not be considered as an interchangeability standard. The tolerances for each type of clamp are to be defined in the parts standards drawings. These clamps are intended for the installation, support and guiding of rigid tubing or hose assemblies.
