ISO 9222-1:1989
M00001090
New product
ISO 9222-1:1989 Technical drawings - Seals for dynamic application - Part 1: General simplified representation
standard by International Organization for Standardization, 07/01/1989
In stock
More info
Full Description
This method indicates only essential features ans should be used when it is not necessary to show the exact shape and details of the seals, for example in assembly drawings. The degree of simplification depends on the kind of object represented, the scale of the drawing and the purpose of documentation. ISO 9222-2 deals with the detailed simplified representation.
