Full Description

Establishes metric mounting dimensions for compact-series cylinders with bores from 250 mm to 500 mm, 16 MPa, as required for interchangeability of commonly used hydraulic cylinders. Only applies to the dimensions of manufactured products. Does not apply to their functional characteristics.
