Full Description

This International Standard specifies the principal characteristics of synchronous endless belts and pulleys for use in synchronous belt drives¹⁾ for mechanical power transmission and where positive indexing or synchronization may be required.

The principal belt and pulley characteristics include:

nominal belt tooth dimensions;belt tooth pitch spacing;belt length and width dimensions;belt length-measurement specifications;pulley groove dimensions and tolerances;pulley diameter and width dimensions and tolerances;pulley quality specification.

1) Synchronous belt drives have been known by various titles in the past: for example, timing belt drives, positive belt drives, gear belt drives.

Product Details

Published: 12/01/1999 Number of Pages: 37 File Size: 1 file , 350 KB Same As: BS ISO 13050:1999, BS ISO 13050:1999
