ISO 128-50:2001
M00008196
New product
ISO 128-50:2001 Technical drawings -- General principles of presentation -- Part 50: Basic conventions for representing areas on cuts and sections
standard by International Organization for Standardization, 04/15/2001
In stock
More info
Full Description
This part of ISO 128 specifies general principles for representing areas on cuts and sections on technical drawings (mechanical, electrical, architectural, civil-engineering etc.) following the orthographic projection methods specified in ISO 5456-2.
Attention has also been given to the requirements of reproduction, including microcopying in accordance with ISO 6428.
