Full Description

ISO 6162-2:2002 specifies complete general and dimensional characteristics for flange heads, split flange clamps (FCS), one-piece flange clamps (FC) and ports applicable to four-screw, split and one-piece flange clamp type tube and hose connectors for use at pressures of 35 MPa (350 bar) to 40 MPa (400 bar). It also specifies the dimensions of the seals to be used, as well as the grooves to house the seal.

ISO 6162-2:2002 also recognizes the need to accommodate metric screw fasteners, as well as to provide a means to use existing inch screw fasteners.
