Full Description

Establishes an inch series of bores and diameters, and gives definitions. A figure shows the identification of bore and rod dimensions. Tabulates the cylinder bores from 3/4 up to and including 14 inches (table 1), and the piston rod diameters from 1/4 up to and including 10 inches (table 2).
