Full Description

Scope

This standard will provide minimum and optional function, layout, and construction requirements for standard control cabinet designs. It will also include a coding system for specifying standard control cabinets with the required options. This standard will apply to Class 1 and Class 2 power transformers and will not apply to distribution or padmount design transformers.

Purpose

This document will provide users and manufacturers with a set of standard designs that can be easily specified. The document should greatly reduce the engineering time required by manufacturers to create and by users to review control cabinet designs.

Abstract

Revision Standard - Active - Draft.Requirements for the design and construction of control cabinets on power transformers are covered by this standard.

Product Details

ISBN(s): 9781504469005 Number of Pages: 50 File Size: 1 file , 1.6 MB Product Code(s): STDAPE24319
