Full Description

Scope

This standard covers requirements for switching-impulse voltage insulation strength for outdoor ac high-voltage circuit breakers having rated maximum voltages of 362 kV and above.

Purpose

The purpose of this standard is to define the special terms used, to provide a rating structure, and to provide a dielectric test procedure. It specifies methods of testing, conditions during tests, and wave shapes to be used for switching-impulse voltage testing.This standard is intended as an addition to the American National Standards for ac high voltage circuit breakers rated on a symmetrical current basis: C37.03-1964 (R1969); C37.04-1964 (R1969); C37.05-1964 (R1969); C37.06-1971; C37.07-1969; C37.09-1964 (R1969); C37.010-1964 (R1969); C37.12-1969; and their supplements. It is planned to eventually incorporate its contents in these basic circuit breaker standards.

Abstract

- Inactive-Withdrawn.

Product Details

Published: 11/30/1971 ISBN(s): 9781504403054 Number of Pages: 12 File Size: 1 file , 2.2 MB Product Code(s): STDWD03392
