Full Description

Scope

This standard outlines a test procedure for comparing two or more insulation systems in accordance with their expected life at rated temperature. The procedure is limited to insulation systems for alternating-current electrical machines using form-wound pre-insulated stator coils and rated 6900 V and below. It is the intent of this procedure to evaluate insulation systems for use in usual service conditions with air cooling. It does not cover such special requirements as machines enclosed in gas atmospheres, subjected to strong chemicals, to metal dusts, or to submersion in liquids, etc. The procedure includes instructions for testing candidate systems in comparison with known systems having a proven record of service experience and interpretation of the results.

Purpose

The purpose of this procedure is to classify insulation systems for the machinery within the scope of this standard in accordance with their temperature limits by test, rather than by chemical composition. Data from such tests may be used to establish the temperature classification of new insulation systems before they are service proven. Service proven systems must also be tested according to this test procedure.

Abstract

Revision Standard - Superseded.

Product Details

Published: 05/15/1981 ISBN(s): 9781504402538 Number of Pages: 12 File Size: 1 file , 4.7 MB Product Code(s): STDSU08235
