Full Description

Scope

1.1 This standard prescribes insulation levelsand dielectric test requirements for powertransformers where :(1) The transformer insulation levels and dielectrictest requirements are explicitly specifiedto be in accordance with this standard(2) The transformers are to be operated atsystem voltages from 115 kV through 230 kV(3) The transformer has a rating, either singlephaseor three-phase, equal to or greater than30 000 kVA self-cooled or 50 000 kVA forcedcooled1.2 These requirements, when specified, supersedeall requirements relative to insulationlevels and dielectric tests as contained in ANSI/IEEE C57.12.00-1980 [4] ' and ANSI/IEEEC57.12.90-1980 [ 51.1.3 Unless explicitly specified, this standardshall be considered as excluded in the eventof any blanket reference to all current standards.

Abstract

New IEEE Standard - Inactive-Withdrawn.This standard prescribes insulation levels and dielectric test requirements for power transformers where: (1) The transformer insulation levels and dielectric test requirements are explicitly specified to be in accordance with this standard. (2) The transformers are to be operated at system voltages from 115 kV through 230 kV. (3) The transformer has a rating, either single-phase or three-phase, equal to or greater than 30000 kVA self-cooled or 50000 kVA forced cooled.

Product Details

Published: 12/07/1982 ISBN(s): 9780738142968 Number of Pages: 14 File Size: 1 file , 950 KB Product Code(s): STDWD95459
