Full Description

Scope

This guide presents the recommended practices and procedures for direct voltage acceptance and maintenance testing of shielded, laminated dielectric insulated power cable systems rated 5 kV and above. It applies to all types of laminated power cable systems such as paper-insulated lead covered, pipe-type, and pressurized cables that are intended for the transmission or distribution of electric power. The tabulated test levels assume that the cable systems have an effectively grounded neutral system or a groundedmetallic shield.

Purpose

The purpose of this guide is to provide uniform practices and procedures for performing direct voltage acceptance and maintenance tests on shielded, laminated power cable systems in the field and to provide guidelines for evaluation of the test results.

Abstract

Revision Standard - Superseded.The recommended practices and procedures for acceptance and maintenance testing of shielded, laminated dielectric insulated power cable systems 5 kV and above are presented.

Product Details

Published: 09/21/2007 ISBN(s): 9780738155791, 9780738155807 Number of Pages: 30 File Size: 1 file , 660 KB Product Code(s): STDSU95675
