Full Description

Scope

This recommended practice applies only to two winding transformers covered by IEEE Std C57.12.00, IEEE Std C57.12.01, and NEMA ST20. It does not apply to rectifier transformers

Purpose

The purpose of this document is to establish uniform methods for determining the capability of transformers to supply nonsinusoidal load currents of known characteristics.

Abstract

Revision Standard - Superseded.This recommended practice provides calculation methods to conservatively evaluate the feasibility for an existing installed dry-type or liquid-filled transformer, to supply nonsinusoidal load currents as a portion of the total load. This recommended practice also provides necessary application information to assist in properly specifying a new transformer expected to carry a load, a portion of which is composed of nonsinusoidal load currents. A number of examples illustrating these methods and calculations are presented. Reference annexes provide a comparison of the document calculations to calculations found in other industry standards. Suggested temperature rise calculation methods are detailed for reference purposes.

Product Details

Published: 08/15/2008 ISBN(s): 9780738154152, 9780738170213, 9780738154145 Number of Pages: 52 File Size: 1 file , 740 KB Redline File Size: 2 files , 1.7 MB Product Code(s): STDSURL95790, STDSU95790
