Full Description

Scope

This standard allows bridges to provide performance guarantees for time-sensitive (i.e., bounded latency and latency variation) loss-sensitive real-time audio video (AV) data stream transmission (AV traffic). It specifies priority regeneration and controlled bandwidth queue draining algorithms. Virtual Local Area Network (VLAN) tag encoded priority values are allocated, in aggregate, to segregate frames among queues that support AV traffic and queues that support non-AV traffic, allowing simultaneous support of both AV traffic and other bridged traffic over and between wired and wireless Local Area Networks (LANs). To this end, it:a) Defines status parameters that allow the boundaries of a Stream Reservation Protocol (SRP¿¿¿seeClause 351) domain (6.6.4) to be identified and maintained;b) Specifies how the priority information in frames received at SRP domain boundary ports isregenerated.NOTE 1¿¿¿The priorities in frames transmitted from outside an SRP domain to a Bridge inside an SRP domain are remapped in order to ensure that traffic that is not associated with a reservation does not disrupt traffic that is associated with a reservation. Hence, traffic entering an SRP domain that uses priority code point values associated with reserved traffic classes will be re-mapped to priority code point values that are not associated with reserved traffic classes.c) Specifies how priority information is used to determine the traffic classes to be used for time-sensitive streams;d) Defines a credit-based shaper algorithm to shape traffic in accordance with stream reservations

Abstract

Amendment Standard - Superseded.This amendment to IEEE Std 802.1Q defines enhancements to the forwarding and queueing functions of a VLAN Bridge to support the transmission of time sensitive data streams.

Product Details

Published: 01/05/2010 ISBN(s): 9780738161433 Number of Pages: 0 File Size: 1 file , 730 KB Product Code(s): STDSU96007
