Full Description

Scope

This standard covers certain electrical, dimensional, and mechanical characteristics and safety features of single- and three-phase, 60-Hz, mineral-oil-immersed, self-cooled, overhead-type distribution transformers 500 kVA and smaller, high voltages 34 500 V and below and low voltages 7970/13 800Y V and below.

Purpose

This standard is intended for use as a basis for determining the performance, interchangeability, and safety of overhead-type distribution transformers and to assist in the proper selection of this equipment.

Abstract

Revision Standard - Superseded.Certain electrical, dimensional, and mechanical characteristics and safety features of single- and three-phase, 60 Hz, mineral-oil-immersed, self-cooled, overhead-type distribution transformers 500 kVA and smaller, high voltages 34 500 V and below, and low voltages 7970/13 800Y V and below are covered in this standard.

Product Details

Published: 09/20/2011 ISBN(s): 9780738166896, 9780738169897 Number of Pages: 55 File Size: 1 file , 580 KB Redline File Size: 2 files , 1.6 MB Product Code(s): STDSU97129, STDSURL97129
