IEC 61188-5-6 Ed. 1.0 b:2003

M00027041

New product

IEC 61188-5-6 Ed. 1.0 b:2003 Printed boards and printed board assemblies - Design and use - Part 5-6: Attachment (land/joint) considerations - Chip carriers with J-leads on four sides

standard by International Electrotechnical Commission, 01/23/2003

More details

In stock

$50.31

-57%

$117.00

More info

Full Description

Provides information on land pattern geometries used for the surface attachment of electronic components with J leads on four sides. Provides the appropriate size, shape and tolerances of surface mount land patterns so as to ensure sufficient area for the appropriate solder fillet, and also allows for inspection, testing and reworking of resulting solder joints.

Product Details

Edition: 1.0 Published: 01/23/2003 Number of Pages: 37 File Size: 1 file , 380 KB
