GMW3269

Description / Abstract: GMW3269, 5th Edition, April 2016 - Hexalobular Socket Pan Head Tapping Screw and Washer Assemblies with Plain Washer Product Grade A

Introduction

Purpose. This standard specifies the characteristics of hexalobular socket pan head tapping screw and washer assemblies with rounded end. This standard is based on ISO/DIS 14585, ISO 10669 and ISO 10510.

Applicability. The screws covered by this specification are suitable for use in general engineering and nonstructural attachments.

Remarks. Designation: GMW3269 thread ×1.

Example: GMW3269 ST 6.3 × 25.

Where:

ST = Screw Tapping
