Full Description

Dimensions of internal and external splines and of Full Form go gauges and not go feature gauges. Dimensions for straight-sided 90 serrations, line size in to 6 in, serration 3/16 in to 6 in. Tables for shallow and deep splines, and for coarse serrations only. Three grades of fit.

Cross References:
BS 969
BS 1044
BS 1916
BS 2059/1
BS 2059/2
BS 2059/3

Product Details

Published: 12/31/1953 ISBN(s): 0580359522 Number of Pages: 56 File Size: 1 file , 1.4 MB Product Code(s): 00075731, 00075731, 00075731
