Full Description

Dimensions, tolerances and general requirements for sizes above and below 3/16 in. Covers screws of the following types: 90 degrees countersunk and raised countersunk, round, pan, cheese and mushroom with slotted and with recessed heads. Appendices on dimensions of hexagon head screws and hexagon precision nuts in sizes below 3/16 inch; flushness gauge for countersunk heads; penetration of standard gauge points for recessed heads; formulae for dimensions; tables of standard sizes.

Cross References:
BS 57
BS 84
BS 1473
BS 1475
BS 1476
BS 1580
BS 1981
BS 2827
BS 3643
BS 4183
Handbook No. 18

Product Details

Published: 06/30/1958 ISBN(s): 0580353095 Number of Pages: 48 File Size: 1 file , 1.2 MB Product Code(s): 00066687, 00066687, 00066687
