Full Description

Notes on general features of design. Dimensions of blanks for commonly used types of gauges including: plain and screw plug gauges with renewable ends and collet, taper lock, trilock or ball handles; segmental and spherical ended plug gauges; solid type plain and screw ring gauges and plain gap gauges; adjustable screw ring gauges. Design of adjustable caliper gauges. Dimensions of check gauges for taper lock gauging members and handles appended.

Cross References:
BS 122
BS 919
BS 969
ANSI B47.1

Product Details

Published: 06/24/1964 ISBN(s): 0580349241 Number of Pages: 56 File Size: 1 file , 1.8 MB Product Code(s): 00069848, 00069848, 00069848
