Full Description

Principal external dimensions for interchangeable vertical in-line centrifugal pumps, 'U' Type, driven by close coupled electric motors. Metric flange requirements for pump inlet and outlet connections. Pressure and temperature ratings. Basic selection chart defining zone of operation in terms of quantity and differential head. Appendices on derivations of basic selection chart grid, change of speed. Selection charts for pumps operating at 1450, 1750 and 3500 rev/min.

Cross References:
BS 350
BS 599
BS 1560
BS 4082:Part 1
PD 5686
ANSI B16.5

Product Details

Published: 04/30/1969 ISBN(s): 0580050092 Number of Pages: 16 File Size: 1 file , 480 KB Product Code(s): 00093196, 00093196, 00093196
