Full Description

Gauges for general and reference use, and setting plugs for screw ring and thread caliper gauges. Tolerances apply to gauges for screw threads of Whitworth and BA forms. General requirements, tables of tolerances; appendices on conventional illustration of tolerance zones, effective diameter equivalent of pitch and angle errors, thread form of not go effective diameter gauges and setting plugs, examples of the use of tolerance tables.

Cross References:
BS 84
BS 93
BS 811
BS 1044
BS 2517


All current amendments available at time of purchase are included with the purchase of this document.

Product Details

Published: 11/09/1971 ISBN(s): 0580069257 Number of Pages: 46 File Size: 1 file , 820 KB Product Code(s): 00065277, 00065277, 00065277
