Full Description

Specifies dimensions and materials and, where appropriate, tolerances for the following components: base and jig plates, circular and rectangular blanks, bolsters, plates and blocks, clamps, clamp buttons, heel pins and jig feet, sections, nuts, spherical seatings and washers, knobs, 'C' washers and shoulder screws.

Cross References:
BS 249
BS 970:Part 1
BS 1449:Part 1
BS 1452
BS 2485
BS 3189
BS 3643:Part 2
BS 3692
BS 4360
BS 4500

Product Details

Published: 06/28/1974 ISBN(s): 0580083632 Number of Pages: 60 File Size: 1 file , 1000 KB Product Code(s): 00127477, 00127477, 00127477
