Full Description

BS PD IEC/TR 61000-1-7:2016, which is a Technical Report, provides definitions of various electricalpower quantities and the relationship between them under non-sinusoidal conditions, in orderto give clear information on both components in the power factor: the fundamental powerfactor, which is due to the phase difference between the voltage and current at thefundamental frequency, and the non-fundamental power factor, which is related to thedistortion of the voltage and/or current. This Technical Report is applicable only to singlephasesystems.

This Technical Report provides definitions for the three following cases: the general case where the voltage and current are both distorted (Clause 5), the case where the voltage is assumed to be sinusoidal and the current is only distortedwith harmonic components (Clause 6), the particular case where the voltage and current are both sinusoidal (Annex A).Annex B gives information on the fundamental active factor, which is used to describe thebehaviour of a piece of equipment as a load or a generator.
Cross References:
IEC 60050-103:2009
IEC 60050-131:2013
IEC 60050-551-20:2001
IEC TR 61000-4-401
IEC 61557-12:2007
IEC 80000-6:2008
IEEE Std 1459-2010


All current amendments available at time of purchase are included with the purchase of this document.

Product Details

Published: 03/31/2016 ISBN(s): 9780580879999 Number of Pages: 38 File Size: 1 file , 1.4 MB Product Code(s): 30312885, 30312885, 30312885
